Normal construction (up to 60 kN)
Type: MST - Acme thread screw
Type: MSK - Recirculating ball screw
Type: MSP - Planetary roller screw |
|
Normal construction (up to 60 kN) )
Type: MST / MSK / MSP - E
(with el. cut-off) |
![](/uploadfile/image/adeimage/BW1.jpg) |
|
![](/uploadfile/image/adeimage/BW2.jpg) |
Basic hardware (all types): Ancillary equipment:
Rust-free piston rod and receptacle pin, piston rod
secured against torsion, with galvanised joint head
(chrome ball) or galvanised fork head. |
|
Ancillary equipment:
Potentiometer, Pulser, Speedometer, bellows or
protective tube, pedestal bearings, var. spindle
pitches, design for implementation in open space or by
aggressive mediums, safety nut, etc... |
|
|
|
Construction with side-mounted motor (up to 60 kN)
Type: MST / MSK / MSP |
|
Construction with side-mounted motor (up to 60 kN)
Type: MST / MSK / MSP - E
(with el. cut-off) |
![](/uploadfile/image/adeimage/BW3.jpg) |
|
![](/uploadfile/image/adeimage/BW4.jpg) |
|
|
|
Construction with side-mounted worm-gear/motor unit (up to 60 kN)
Type: MST / MSK / MSP |
|
Construction with side-mounted worm-gear/motor unit (up to 60 kN)
Type: MST / MSK / MSP - E
(with el. cut-off) |
![](/uploadfile/image/adeimage/BW5.jpg) |
|
![](/uploadfile/image/adeimage/BW6.jpg) |
|
|
|
Construction with built-on parallel-shaft helical gear box (up to 60 kN)
Type: MST / MSK / MSP |
|
Construction with built-on parallel-shaft helical gear box (up to 60 kN)
Type: MST / MSK / MSP - E
(with el. cut-off |
![](/uploadfile/image/adeimage/BW7.jpg) |
|
![](/uploadfile/image/adeimage/BW8.jpg) |
|
|
|
Construction with integral worm-gear drive (up to 80 kN)
Type: MST / MSK / MSP |
|
Open construction (up to 30 kN)
Type: MST / MSK |
